ADAE AD081 muffle furnace 1600 °C
- In stock, ready to ship
Technical Specifications:
-
Model: AD081.
-
Chamber Size: 100 x 100 x 100 mm (Width × Height × Depth).
-
Maximum Temperature: 1700°C (< 2 hours).
-
Maximum Working Temperature: 0 - 1600°C.
-
Power voltage: 220V/50HZ or 110V/ 60HZ.
Temperature Controlling:
-
PID automatic control via SCR (Silicon Controlled Rectifier) for power control with phase angle firing and current limiting resistor.
-
51 programmable segments for precise control of heating rate, cooling rate, and dwell time.
-
Built-in PID Auto-Tune function with overheating and broken thermocouple protection.
-
Over-temperature protection and alarm for unattended operation.
Performance Parameters:
-
Temperature Accuracy: ± 1°C.
-
Temperature Uniformity: ± 5°C.
-
Heating Rate: 0 - 20°C per minute.
-
Thermocouple Type: B type.
Packaging and Weight:
-
Single Package Size: 65 x 98 x 112 cm.
-
Single Gross Weight: 68 kg.
Packing list
-
Electric Furnace (1 set)
-
SiMo2 Heating Element (2 pcs)
-
High-Temperature Gloves (1 pair)
-
Crucible Clip (1 pc)
-
Operation Manual (English version) (1 book)
Warranty
One year
